Description
The Trijicon Credo 2900016 is a 1-6x x 24mm rimfire scope from Trijicon built on a 30mm tube with a Illuminated BDC Green LED Segmented Circle .223 55gr reticle in the second focal plane.
Trijicon Credo 2900016 Overview
A rimfire scope is built around the short ranges and light recoil of 22 LR and 17 HMR rifles, usually with the parallax set closer than a centerfire scope so targets at 50 to 100 yards stay crisp.
A rimfire scope is not built for heavy centerfire recoil, so keep it on the rimfire, airgun or light rifle it was designed for.
Optics and Reticle
Magnification runs 1-6x with a 24mm objective lens. The distributor lists a field of view of 113.40-18.80 ft @ 100 yds. The reticle is listed as Illuminated BDC Green LED Segmented Circle .223 55gr. Lens coating: Multi-Coated.
In a second focal plane scope the reticle stays the same size as you zoom, which keeps it easy to see at low power. Holdover or ranging marks are only exact at the magnification the maker specifies, usually the highest setting.
Turrets and Adjustments
Adjustments move 25 MOA per click with 29.10 MRAD of total elevation and 29.10 MRAD of windage. Zero the turrets at your chosen distance and note how many clicks you need for longer shots.
Mounting and Fit
The 30mm main tube needs matching 30mm scope rings or a one-piece mount. Eye relief is listed as 3.50″ – 3.90″, so set the scope far enough forward that recoil cannot drive the eyepiece into your brow, then level the reticle and confirm you get a full sight picture with a natural cheek weld. Listed length is 10.90″.
Build and Durability
The tube is aluminum, finished in matte black, and the distributor lists it as fog proof / shockproof / waterproof. Listed weight is 18.90 oz. Check ring screw torque after the first range session and again before hunting season.
Honest Limitations
Every scope involves trade-offs. More magnification brings a narrower field of view, more visible shake and more heat mirage on warm days, and a larger objective adds weight and height over the bore. Budget and mid-priced scopes can be excellent values, but their adjustments and low-light performance do not match premium glass, so match the scope to how and where you hunt or shoot.
Low-light performance depends on the objective size, coatings and your own eyes as much as the spec sheet, so compare scopes at dusk if you can.
Sighting In
Bore sight first, then fire a three-shot group at 25 yards to get on paper and move to 100 yards to refine. A 100-yard zero is the common starting point for centerfire hunting rifles, 50 yards for rimfires, and the distance your ballistic data assumes for long-range work. Confirm the zero with the exact ammunition you plan to use.
Care and Storage
Keep lens caps on in the field, clean the glass with a lens brush and microfiber cloth instead of a shirt tail, and store the rifle where temperature swings will not fog the optics. Recheck zero after any hard knock or after travel.
Before You Buy
Confirm the ring size, mounting height and the distances you shoot most. Riflescopes are not firearms and ship without an FFL transfer.
Specifications
- Brand: Trijicon
- Model: Credo
- Magnification: 1-6x
- Objective: 24mm
- Tube: 30mm
- Reticle: Illuminated BDC Green LED Segmented Circle .223 55gr
- Focal plane: second focal plane
- Click value: 25 MOA
- Elevation: 29.10 MRAD
- Windage: 29.10 MRAD
- Field of view: 113.40-18.80 ft @ 100 yds
- Eye relief: 3.50″ – 3.90″
- Finish: Matte Black
- Length: 10.90″
- Weight: 18.90 oz
- UPC: 719307403031
Who It Is For
The Trijicon Credo 2900016 is a great fit for 22 LR and 17 HMR shooters, plinkers and small-game hunters.
Buy the Trijicon Credo 2900016 at MAG5 Firearms
MAG5 Firearms is a family-owned FFL in Collegeville, Pennsylvania. Order the Trijicon Credo 2900016 online, or browse our riflescopes and scope mounting for rings and bases. For factory details, visit Trijicon.
